Wi-Fi
Wi-Fi module supplied as standard, comes with 10m extension cables for improved connectivity (can be easily removed) – requires iOS / Android ‘Smart Life’ App
Intelligent operation
Three preset modes; Powerful mode maintains high heat output for fastest heating, silent mode keeps heat pump below 55% heat output for quietest running, smart mode allows heat pump to use full range of heat output for maximum flexibility and efficiency
Simple connections
9kW and 12kW models come factory fitted with 2.8m mains cable and UK RCD plug suitable for outdoor 13A sockets
1.5 inch female threaded water connections, use the supplied unions for pressure pipe, or you can use optional threaded hose tails for connecting 32mm or 38mm hose
Flexible heating
Heats from 5°C to 40°C, can also be used for cooling
All season model works down to -15°C, automatic hot gas defrosting keeps heat pump working even in minus temperatures
Quality by design
Black ABS weather and corrosion resistant cabinet with covered LCD display
Large heat exchanger for increased efficiency in lower temperatures
High efficiency performance with advanced full DC inverter system that automatically controls the running speed of the compressor and the fan
Low noise airstream design for very quiet operation, average sound level 45 dB(A) at one metre
High quality Toshiba or Mitsubishi compressor (see individual specifications)
EEV (Electronic Expansion Valve) throttling technology adjusts the gas flow and increases COP by up to 20%
Spiral Titanium heat exchanger is 40% more efficient than standard titanium heat exchanger
R32 gas for environmentally friendly operation
Winter cover included as standard (keeps debris out of unit when not in use)
Designed with Koi owners in mind
Heats from 5°C to 40°C
1°C differential to restart (differential below 1°C can affect efficiency)
Factory fitted mains cable on 9kW and 12kW plugs directly into 13A outside socket
10m extension cable on Wi-Fi module for improved connectivity to home Wi-Fi networks (removable if not needed)
Inverter model is suitable for all year round heating / cooling
Large heat exchanger for improved efficiency at lower temperatures
Remote input for external thermostat with probe
Technical Data
Heating Capacity A27/W26 |
9.03 kW |
Heating Capacity A15/W26 |
5.94 kW |
Heating Capacity A28/W28 |
30,812 BTU/hr |
Max. Input Power |
0.12 ~ 1.35 kW |
Max. Current |
6.8A |
Minimum Fuse (C Type MCB) |
2.8m cable, RCD and UK plug fitted – needs 10A MCB if hardwired |
COP A24/W26 |
6.3 ~ 17.5 |
COP A15/W26 |
5.1 ~ 8.2 |
Voltage |
230V |
Compressor |
GMCC (Midea/Toshiba) |
Refrigerant |
R32 |
Noise Level (10m) |
<29db |
Nominal Flow |
3-5m³/h |
Water Connections |
1½ inch |
Dimensions (L x W x H) |
826mm x 379mm x 552mm |
Weight |
35Kg |
Wi-Fi Connectivity |
Built-in* (Requires Smartphone App) |
